Detail Send

Input signal: 4 – 20mADC

Air Supply: 0.14 – 0.5Mpa (140 – 500kPa)

Feedback signal: 4 – 20mA

Explosion proof and IP66

HART comunication (HART 7)

Detail Send

Input Signal: 4 – 20mADC

Air Supply: 0.14 – 0.7MPa (140 – 700kPa)

Linear motion: 10 – 100mm

Rotary motion: 60 – 90º

Protection dust & drip-proof: IP65

Flame-proof: Ex d II B T6

Flame-proof H2: Ex d II B + H2 T6

Detail Send

Input Signal: 20 – 100kPa

Air Supply: 0.14 – 0.7MPa (140 – 700kPa)

Linear motion: 10 – 100mm

Rotary motion: 60 – 90º

Pressure gauge: 0 – 0.2MPa; 0 – 0.4MPa; 0 – 1.0MPa

Housing: Dust & Weather proof

Detail Send

Input Signal: 4 – 20mADC

Air Supply: 0.14 – 0.7MPa (140 – 700kPa)

Linear motion: 10 – 100mm

Rotary motion: 60 – 90º

Protecion dust & drip-proof:IP65

Explosion-proof: Ex d II BT6

Option: Positioner Transmitter (4 – 20mADC)

Detail Send

Input Signal: 20 – 100kPa

Air Supply: 0.14 – 0.7MPa

Stroke: 12 – 50mm with clamp,40 – 100mm with clamp

Housing: Junction box unit

Dust proof & weather proof
